• High starting torque: 150%/1Hz, ideal for demanding machinery
• Built-in safety stop function – compliant with EU Machinery Directive
• Easy, maintenance-free spring clamp terminals
• Long-life design with 10-year component durability
• Multiple control and tuning options
• Enhanced communication protocols for system integration
• Optional operation panels and PC-based configurator tools

• Compact Design: The FR-D700 Series features a reduced installation footprint, enabling bookshelf mounting and increased installation density in control panels.
• Energy Efficiency: Equipped with an Optimal Excitation Control (OEC) function, these inverters optimise current and power consumption, leading to additional energy savings compared to conventional inverters.
• Long Service Life: Designed for over 10 years of service life, the FR-D700 Series utilises high-performance heat-resistant capacitors, sealed-bearing cooling fans, and conformal coating on circuit boards to withstand aggressive environments.
• Enhanced Safety: The integrated “Safe Torque Off” (STO) function complies with EN 61800-5-2 standards, disconnecting power from the motor to prevent unexpected restarts and ensure operator safety.
• Advanced Control Functions: Features like sensorless vector control, autotuning, regeneration avoidance, and built-in PID control enable precise and efficient motor control across various applications.
• User-Friendly Operation: The FR-D700 Series supports simple cabling, easy parameterisation, and offers integrated control units. Additionally, the FR Configurator software allows for quick setup and monitoring via a personal computer.
• Robust Communication Capabilities: Built-in RS-485 communication supports both Mitsubishi inverter protocol and Modbus-RTU, facilitating seamless integration into various control systems.

The Mitsubishi FR-D700 Inverter for Industrial Use is ideal for numerous automation and industrial applications that require space-saving, durability, and precise motor control. Typical industries include:

By providing high torque at low frequencies and robust diagnostic functions, the FR-D700 ensures stable, safe, and efficient operation in all these scenarios.

The Mitsubishi FR-D700 Inverter for Industrial Use includes a built-in safety stop function, eliminating the need for costly external safety hardware. In the event of an emergency stop signal, the inverter immediately halts motor output with high reliability.

Certified to international safety standards, this feature helps you meet EU Machinery Directive requirements cost-effectively.

Forget screw retightening. The Mitsubishi FR-D700 Inverter for Industrial Use uses spring clamp terminals for the control circuit, offering:

• Tool-free, secure wiring with or without blade terminals
• Resistance to vibration – no contact faults
• Quick installation and no periodic maintenance

Mitsubishi has extended the design life of key components:

• Cooling fans and capacitors rated for 10 years (40°C average)
• Leading life check function monitors component wear
• Self-diagnostic alarms help prevent unexpected downtime

Component	FR-D700 Life	Industry Standard (JEMA)
Cooling Fan	10 years	2–3 years
Main/Printed Board Capacitors	10 years	5 years

The Mitsubishi FR-D700 Inverter for Industrial Use supports general-purpose magnetic flux vector control, ideal for operations requiring high torque and precise speed control.

• 150% torque at 1Hz and 200% at 3Hz (3.7kW or less)
• Ideal for conveyors, hoists, agitators, lifts
• Non-rotation auto-tuning for quick motor setup
• Supports a wide range of motor types

A brake transistor is built-in for models 0.4kW and above. Connect an optional brake resistor to:

• Increase regenerative braking capacity
• Enable safe and quick stops for high-inertia machines

The Mitsubishi FR-D700 Inverter for Industrial Use includes premium functions from Mitsubishi’s advanced inverter models:

• Regeneration Avoidance: Avoids trip errors by adjusting output when reverse rotation occurs
• Optimum Excitation Control: Increases energy efficiency in variable load torque applications like fans and pumps
• Power Failure Deceleration: Decelerates the motor safely in power loss scenarios
• Dancer Control: PID-based tension control for dancer roll systems
• Traverse Function: Ensures consistent winding in textile and cable operations

The Mitsubishi FR-D700 Inverter for Industrial Use Series includes several models to accommodate different power requirements and input types:

• FR-D720 Series: Three-phase 200V input models ranging from 0.1 kW to 15 kW.
• FR-D740 Series: Three-phase 400V input models ranging from 0.4 kW to 15 kW.
• FR-D720S Series: Single-phase 200V input models up to 2.2 kW.
• FR-D710W Series: Single-phase 100V input models up to 0.75 kW.

Each model is designed to meet specific application needs, ensuring flexibility and adaptability across various industrial settings.

For more detailed information, including technical specifications and product documentation, you can visit the official Mitsubishi Electric Africa website: Mitsubishielectric.com

Mitsubishi’s signature setting dial allows you to:

• Quickly jump between values by turning rapidly
• Precisely adjust parameters by turning slowly
• Benefit from a nonslip, easy-to-use dial

Connect a PC to the D700 via RS-485 and use the FR Configurator software for:

• Wizard-based setup for intuitive configuration
• Waveform graphing and live monitoring
• Easy migration from older FR-S500 inverters using the “Convert” function

• Mounts to the panel surface
• Compatible with select FR-E500 panels
• Requires a separate FR-CB20□ connection cable

• Numeric keypad with direct input
• Multilingual support – 8 languages
• Displays operation status and includes a help function
• Store parameter settings for up to three inverters
• Requires FR-CB20□ cable for connection

• Mitsubishi inverter protocol
• Modbus-RTU
• Improved RS-485 speed – up to 38.4kbps
• Multi-command mode for faster data processing

✔ Easy installation and maintenance
✔ High performance in compact design
✔ EU-compliant safety stop function
✔ High torque for demanding loads
✔ Advanced diagnostics and tuning features
✔ Flexible setup via PC or optional panels
✔ Seamless integration with industrial networks
✔ Trusted in diverse sectors: from food processing to material handling
